Maintenance
• “Inspection guide” on page 313
• “Scheduled maintenance” on page 314
• “Preventive maintenance” on page 314
• “Lubrication specification” on page 315
• “Cleaning the printer” on page 315
Inspection guide
The purpose of this Inspection guide is to aid you in identifying the intervals, based on page count, at which parts must
be Inspected (for visible physical damage), cleaned, or replaced.
If any unsafe conditions exist, find out how serious the hazard could be and if you can continue before you correct the
hazard.
As you service the machine, check for the following:
• Damaged, missing, or altered parts, especially in the area of the On/Off switch and the power supply
• Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover
• Possible safety exposure from any non-Lexmark attachments
Use the following tables to determine when specified parts should be Inspected:
Lexmark CS310, CS410, and
CS510
Every service
call
Every 85K Notes
Media tray - All
Media tray side guides Inspect Check for correct positioning
Media tray length guides Inspect Check for correct positioning
Transfer module (ITM) Inspect Replace Ensure correct installation
Fuser Inspect Replace Ensure correct installation
Media feeders - All
Media tray pick tires Inspect, clean if needed Clean with a damp cloth
MPF pick tires Inspect, clean if needed Clean with a damp cloth
Paper path
Duplex path rollers Inspect Check for media fragments and tears
Check for excessive toner buildup on white rollers
Clean with damp cloth if needed
Miscellaneous
Toner spillage Clean Use a toner vacuum and cloth to remove all toner
spillage from the printer
5027
Maintenance
313
