Connector Connects to Pin no. Signal
JTPS1 TPS1 connector 1 CATHODE
2 ANODE
3 Ground (no wire)
4 +5V_SW
5 Ground
JTPS2 TPS2 connector 1 ANODE
2 CATHODE
3 Ground (no wire)
4 +5 V_SW
5 Ground
JTRAY1 Bottle sensors 1 +5V_SW
2 DUPLEX_ENT, +5 V dc
3 Ground
JUSB1 Port USB connector N/A N/A
JUSBW1 USB wireless connector 1 Ground
2 USB_HST_VP
3 USB_HST_VM
4 Ground
5 +5 V dc
6 +3.3 V dc
JWT1 Waste toner detection 1 SENSE
2 VREF
3 +1.5 V dc
4 Ground (no wire)
5027
Component locations
312

Lexmark CS310 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 60, 000 pages
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Standard Output Capacity	125 sheets
Recommended Monthly Page Volume	500 - 3, 000 pages
Operating Systems Supported	Windows, Linux
