Actions Yes No
Step 3
Are the USB ground contacts attached to the USB connections on the
controller board and controller board cage?
Go to step 5. Go to step 4.
Step 4
Install the USB ground contacts in the controller board.
Did this fix the problem?
Problem solved. Go to step 5.
Step 5
Turn the printer off, and remove the rear cover. See
“Rear cover removal”
on page 290.
Is the LVPS cable correctly connected at JLVPS1 on the controller board?
Go to step 6. Reconnect the cable at
JLVPS1, and then go to
step 6.
Step 6
Turn the printer off, and then on.
Does the problem persist?
Go to step 7. Problem solved.
5027
Diagnostic information
118
