Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1‑1 40X7643 1 1 Controller board cover
(CS310, CS410)
“Controller board removal” on page 291
1 40X7644 1 1 Controller board cover
(CS510, C2132)
“Controller board removal” on page 291
2 40X7633 1 1 Top cover assembly
“Top cover assembly removal” on
page 294
3 40X7621 1 1 Toner supply door
“Toner supply door removal” on page
233
4 40X9244 1 1 Bracket, front toner door
pivot
N/A
5 40X7630 1 1 Right cover assembly
“Right cover assembly removal” on
page 232
6 40X7645 1 1 250‑sheet tray assembly
“Paper pick motor drive assembly
standard tray removal” on page 287
7 40X5803 1 1 Duplex reference edge
“Duplex reference edge removal” on
page 265
8 40X7619 2 2 Front cover straps
“Front cover assembly removal” on
page 252
9 40X7635 1 1 Front cover assembly
“Front cover assembly removal” on
page 252
10A 40X7638 1 1 Operator panel and display
assembly (CS310)
“Operator panel removal (for CS310
models only)” on page 254
10B 40X7640 1 1 Operator panel (CS410)
“Operator panel removal (for CS410
models only)” on page 256
10C 40X7642 1 1 Operator panel (CS510,
C2132)
“Operator panel removal (for CS510
models only)” on page 259
11 40X5168 2 2 Pick tires
“Pick tire removal” on page 303
12 40X7650 1 1 UICC card (CS510, C2132)
“Operator panel removal (for CS510
models only)” on page 259
13 40X7651 1 1 2.4” Display and UICC card
(CS410)
“Operator panel removal (for CS410
models only)” on page 256
14 40X7116 1 1 4.3” Display
“Operator panel removal (for CS510
models only)” on page 259
5027
Parts catalog
318
