Lexmark CS310 - Page 322

Assembly 2: Frames
Asm-index P/N Units/mach Units/FRU Description Removal procedure
2-1 40X7627 1 1 Printhead laser N/A
2 40X7629 1 1 Fuser drive motor assembly
“Fuser drive motor assembly
removal” on page 234
3 40X7646 1 1 Lower left frame and lower right
frame with cable cover
“Lower left frame removal” on
page 273, “Lower right frame
removal” on page 280
4 40X7652 1 2X Spring parts package
• Tray‑bias spring (2)
• Fuser latch spring (2)
• Image transfer unit front hold
down spring (2)
• Front cover latch spring (2)
N/A
5 40X7610 1 1 Image transfer unit
“Image transfer unit (ITU) removal”
on page 243
6 40X7614 1 1 Paper pick motor drive assembly,
standard tray
“Paper pick motor drive assembly
standard tray removal” on page
287
7 41X0001 1 1 Drive unit motor
“Drive unit motor removal” on
page 220
8 40X7628 1 1 EP drive gear assembly, with motors
“EP drive assembly removal” on
page 221
9 40X7622 1 1 Fuser assembly, 115 V
“Fuser assembly removal” on
page 267
9 40X7623 1 1 Fuser assembly, 230 V
“Fuser assembly removal” on
page 267
9 40X7624 1 1 Fuser assembly, 100 V
“Fuser assembly removal” on
page 267
10 40X7649 1 1 Exit deflector assembly parts packet
• Exit deflector
• Bin‑full/narrow media sensor
flag
• Right output bin deflector
“Exit deflector removal” on
page 269, “Bin‑full/narrow media
sensor flag removal” on page 231,
“Right output bin deflector
removal” on page 271
5027
Parts catalog
322
