Assembly 5: Media drawers and trays
Asm-index P/N Units/mach Units/FRU Description Removal procedure
5-1 40X8089 1 0 Optional 650‑sheet duo drawer
(complete)
(includes 100‑sheet MPF)
“650‑sheet duo drawer assembly
removal” on page 301
2 40X5168 2 2 Pick tires
“Pick tire removal” on page 303
3 40X8091 1 1 650‑sheet Duo Drawer tray
assembly
“650‑sheet duo drawer tray assembly
removal” on page 300
4 40X8090 1 1 Optional 550‑sheet drawer
(complete)
(CS410, CS510, and C2132 only)
N/A
5027
Parts catalog
330
