Actions Yes No
Step 3
Enter Diagnostics Menu.
For CS310 models, turn the printer on, press and hold Down and Right,
and release the buttons with the installed memory and processor speed
displays.
For CS410 and CS510 models, turn the printer on, press and hold 3 and
6, and release the buttons with the installed memory and processor speed
displays.
Perform the Base Sensor Test. See
“BASE SENSOR TEST” on page 176.
a Select Base Sensor Test, and press Select.
b Select S2 Sensor, and press Select.
c Pull tray 1 out, and rotate the S2 sensor flag (A). (The S2 sensor is
located in the front of the center paper pick motor drive assembly
housing.) It should rotate freely and return to its original position.
d Watch the display while pushing up on the flag.
Does the display indicate Media Clean and Media Present?
Problem resolved. Go to step 4.
5027
Diagnostic information
51

Lexmark CS310 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 60, 000 pages
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Standard Output Capacity	125 sheets
Recommended Monthly Page Volume	500 - 3, 000 pages
Operating Systems Supported	Windows, Linux
