Linde E35 - Control Buttons

4
Operation
Display unit
Control buttons
1
4
2
3
EFF
EFF
Display_e0009b
The display unit has four control buttons.
Back button (1)
Briefly press the "Back" butto
n to perform the
following action:
• Move back one level.
Press and hold down the "Back button" to
perform the following action:
• Move back to the top level
Up button (2)
Briefly press the "Up arrow
button" to perform
the following action:
• Move up by one row.
Down button (3)
Briefly press the "Down" button to perform the
following action:
• Move down by one row.
1600
10,2
EFF
EFF
5
°
kg
Display_e0010a
Confirm button (4)
Briefly press the "Confirm" button to perform
the following actions:
• Activate the menu point shown on the
display (5) (marked in red).
• Confirm entry.
• Confirm the message.
NOTE
Button tones are deactivated as default in the
factory settings. They can be activated using
the diagnostic program.
92 Operating Instructions – 3888011701 EN – 12/2017
