Linde E35 - Battery Hood Opening - Closing

Operation
4
Drive batteries
Battery hood
Opening - Closing
The battery hood must be opened in the
following circumstances:
• Replace the battery
• Performing battery mainte
nance
• Opening the hinged battery door
• Changing fuses
CAUTION
Possible damage to the joysticks in the battery hood
end position.
Adjust the driver's seat, armrest and steering
column so that the joysticks do not touch the roof of
the truck frame when the battery hood is folded up
to its end position.
Opening the battery hood
NOTE
Remove any loose items from the battery hood
or from under the driver's seat prior to opening.
e3871442
 Use the lever (1) to release the interlocks
for the rear window (special equipment) and
fold up the window to the rear as far as the
end stop.
 Move the steering column all the way
forwards.
 Fold in the driver's seat backrest.
 Move the driver's seat and armrest back-
wards.
Operating Instructions – 3888011701 EN – 12/2017 165
