4
Operation
Operation
1
2
3
4
e3861546a
Electronically locked
Push the joystick (4) forwards by at least
40% (depending on the configuration) and
then move it to the zero position.
6
Display_e0039a
Thejoystickisunl
ocked for approximately one
second and the disp
lay (6) lights up in green in
the display unit.
NOTE
If the joystick is not moved forwards within this
time period, it is locked again.
Push the joystick (4) forwards.
Clamp opens.
Once the joystick has been released, it is
locked again within one second.
Pull the joystick (4) backwards.
Clamp closes.
Load-dependent assistance system
(load weight indicator "plus")
The load-dependent assistance system
reduces the risk of tipping and increases the
stability of the truck.
• Thisisac
hieved by actively intervening in
the lifti
ng and tilting movements. In addition,
there is t
he option to intervene in the driving
speed.
• The load centre of gravity is not taken
into account. Consult the load capacity
diagram.
140 Operating Instructions – 3888011701 EN – 12/2017
