Linde E35 - Replacing the Battery on a Truck with an Elevated Drivers Compartment

Operation
4
Drive batteries
1
e3871472
Replacing the battery on a truck with
an elevated driver's compartment
For trucks with an elevated driver's compart-
ment, when replacing a battery using a truck
and a battery removal tool, the left-hand side
door (1) on the truck must also be opened
so that the hooks of the removal tool can be
hooked into the corresponding openings (see
arrows) in the battery tray.
e3871473a
12
Ontruckswithanel
evated driver's compart-
ment, the push-but
ton to unlock the right-hand
battery door (1) is
actuated through the ope-
ning (2).
Operating Instructions – 3888011701 EN – 12/2017 187
