Technical data

Lift mast data 388 series elevated driver's compartment

Standard

lift mast (in mm)

E40/600H

E45/600HL

Lift

h 3 3800 4100 4400 5000 5400

Lift mast retracted h 1 2710 2860 3010 3310 3510

Lift mast extended

4700 5000 5300 5900 6300

Free lift

150 150 150 150 150

Triplex

lift mast (in mm)

E40/600H

E45/600HL

Lift h 3 5715 6015

Lift mast retracted h 1 2760 2860

Lift mast extended

6615 6915

Free lift

1860 1960

294 Operating Instructions – 3888011701 EN – 12/2017
