Linde E35 - Adjusting the Steering Column; Angle Adjustment

Operation
4
Driver's compartment
Adjusting the steering column
DANGER
It is not possible to drive safely when the clamping
screw is open.
Only adjust the steering column when the truck is
stationary.
Before attempting to drive the truck, ensure that the
steering column is locked.
Angle adjustment
e3861363a
 Undo the clamping screw (see arrow) by
turning it in an anticlockwise direction.
 Move the steering wheel into the required
position.
 Tighten the clamping screw by turning it in a
clockwise direction.
Height adjustment (special equipment)
 Undo the clamping screw (see arrow) by
turning it in an anticlockwise direction.
 Move the steering wheel into the required
position by pulling it upwards or pushing it
downwards.
 Tighten the clamping screw by turning it in a
clockwise direction.
Operating Instructions – 3888011701 EN – 12/2017 71
