5
Service work
Self-help
2
1
3
e3871518
Fuses -
Basic equipment
The main current fuses (3) and the fuse
holder (1) with the plug-in fuses for the basic
equipment are located on the contactor board
(2) under the right-hand truck console.
e3871135
To access the fuses, the front right-hand side
panelling (see arrow) must be removed.
266 Operating Instructions – 3888011701 EN – 12/2017
