Service work
5
Chassis frame
Chassis frame
Wheel change
DANGER
Risk of tipping.
All tyres on any one axle must be of the same
dimensions, from the same manufacturer and of
the same type and profile.
WARNING
Observe the tare weigh
tofthetruck.
Only use hydraulic ja
cks with a load capacity of at
least 5000 kg.
CAUTION
Electrostatic charge.
When using non-marking tyres (light-coloured
tyres), the electrical potential equalisation must
be ensured with an antistatic belt
The antistatic belt must always be in contact with
the ground.
Only position the rear hydraulic jack cen-
trally under the counterweight.
Position the front hydraulic jack on the left
or right-hand edge of the chassis or on the
lift mast.
The truck may be jacked up only at these lifting
points at the front left, front right and the rear
middle.
Loosen the wheel fastenings on the wheel
in question.
Lift the truck using a hydraulic jack until the
wheels are off the ground.
Support the truck securely using hardwood
supports at the chassis or at the counter-
weight (to remove the load from the hy-
draulic jack).
Unscrew the wheel fastenings.
Change the wheel.
Position the wheel fastenings and hand-
tighten.
Lower the truck.
Operating Instructions – 3888011701 EN – 12/2017 227
