Technical data
6
Lift mast data
Lift mast data
The lift mast data applies to the standard design with solid rubber tyres and a fork carriage.
This data must be observed without fail.
Standard
Lift mast (in mm)
E35/600H
E40/600H
E45/600H
E40/600HL
E45/600HL
E50/500HL
E50/600HL
Lift h 3 3100 3700 4100 4400 5000 3200 3700 4100 4400 5000
Lift mast retracted
h 1 2404 2704 2904 3054 3354 2554 2804 3001 3154 3454
Lift mast extended
h4
4000 4600 5000 5300 5900
-----
Free lift
h2
150 150 150 150 150 150 150 150 150 150
Triplex
Lift mast (in mm)
E35/600H
E40/600H
E45/600H
E40/600HL
E45/600HL
E50/500HL
E50/600HL
Lift h 3 4675 5515 6015 4375 4615 5065 5565
Lift mast
retracted
h 1 2360 2660 2860 2360 2660 2860 2860
Lift mast
extended
h4
5575
6415 6915
5575
6415 6915 6915
Free lift
h2
1460 1760 1960 1460 1760 1960 1960
.
Operating Instructions – 3888011701 EN – 12/2017 293
