Safety
2
Towing
e3871501
1
2
3
4
5
Insert the lever (5) into the opening (4)
provided in the front wall and place the lever
on the tappet (3).
Move the lever downwards appr
ox. 20
times (pump the lever).
This results in a build-up of pressure and
releases the multi-disc brake.
NOTE
To release the multi-disc brake in the drive
wheel units, an accumulator is also used to
supply the brake valve.
DANGER
Acute risk of injury whe
n working on accumulator.
Improper handling may
lead to serious accidents.
Before starting repai
r work on the accumulator
or on any pressurised
hydraulic pipework, the
accumulator must be d
epressurised.
Appropriate specia
list knowledge is required for
this task. Contact
your service partner.
Towing
Tow the truck. If possible, steer the truck
while it is being towed.
After towing
Use wheel chocks on the side of the truck
facing downhill.
Shut down the t
ruck.
Operating Instructions – 3888011701 EN – 12/2017 27
