4
Operation
Workingwithaload
Push-pull function
NOTE
Observe the operating instructions from the
attachment manufacturer.
12
3
e3861462a
When using the "push-pull"(1) attachment, a
pushing mechanism (2) pushes the load off
aplate(3)orofftheloadforkoftheindustrial
truck for storage.
If the driver's line of sight is obscured, there
is a danger that the pushing mechanism may
push the goods against the edge of the rack
or against the side panel of a truck, thereby
damaging the goods.
In certain applications, it may therefore be
desirable for the truck to roll backwards
without the accelerator pedal being actuated
when the load is pushed off.
NOTE
In order to activate the push-pull function, a
special diagnostic program is required. When
commissioning this function, the driver must
also be instructed on its use. Contact your
service partner.
When the relevant joystick is actuated, the
parking brake that usually engages is deacti-
vated.
When pushing the load against the edge of a
rack, the truck will slowly roll back (at creep
speed, < 2 km/h).
The parking brake is activated again as soon
as the joystick returns to the neutral position.
DANGER
Risk of accident on ramps! If the push-pull function
is activated on a ramp, the truck will no longer be
held in position by the parking brake that usually
engages. The truck will slowly roll down the ramp.
If you do not want the truck to roll backwards, it must
be secured against rolling away.
162 Operating Instructions – 3888011701 EN – 12/2017
