4
Operation
Display unit
Favourites display menu
1
13
EFF
km/h
Display_e0012a
Press the button.
Use the
or buttons to select the
desired favourites display (1).
Press the
button to confirm.
The following favourites can be selected:
• Steering angle/time/operating hours
• Steering angle/time/driving speed
• Driving speed/steering angle
• Steering angle/tilt angle/load weight (spe-
cial equipment)
• Tilt angle (factory setting)/load weight
(special equipment)
NOTE
The Favourites display saves the last dis-
played view and displays this view again after
the electrical system has been switched back
on.
NOTE
If a value of 0° is displayed for the tilt angle,
the fork arms are not necessarily horizontal.
Deviations may occur due to uneven ground,
use of the truck on slopes, bends in the lift
mast and fork arms caused by heavy loads,
tyre wear or the tyre deflection.
94 Operating Instructions – 3888011701 EN – 12/2017
