Service work
5
Inspection data and maintenance data
Inspection data and maintenance data
Unit Devices/consumables
Filling quantity/set values
Distilled water
Battery
Acid-free grease
As required
Traction motor/hydraulic motor
Electric cleaner
As required
Suctionfilter-degreeof
filtration: 15 µm
Filter insert
Pressure filter - degree of
filtration: 6 µm
Lift height up to 5165 mm: ap-
prox. 22 l
Hydraulic system
Hydraulic oil
Lift height of 5175 mm or
higher: approx. 31 l
Front: 425 Nm
Wheel fastenings Tighten
Rear: 460 Nm
Single tyre
Initial filling: 1.3 l
Oil change: 1.15 l
Planetary transmission
Gearbox oil
Twin tyres
Initial filling: 1.4 l
Oil change: 1.25 l
Steering axle
Lubricating grease
As required
Guidefortheliftmastand
chain guide
Linde chain spray
As required
.
Operating Instructions – 3888011701 EN – 12/2017 209
