Linde E35 - Electrolyte Circulation Pump (Special Equipment) - Checking the Filter

5
Service work
Electrical enclosure
Electrolyte circulation pump (special
equipment) - Checking the filter
34
1
2
e3871431a
The electrolyte circulation pump is fitted
in conjunction with the integrated charger
(special equipment); both are fitted behind the
rear cover on the counterweight.
1
Pump
2Hose
3
7-pin plug
4
Integrated charger
12
3
4
e3861430
An integrated suc
tion filter (1) is fitted at the
bottom of the circ
ulating pump (4).
 Check the suction filter for contamination
and replace if necessary.
 Check the hose at the connection (3) for
damage and replace if applicable.
1
Suction filter
2
7-pin plug
3 Hose connection
4
Pump
.
246 Operating Instructions – 3888011701 EN – 12/2017
