Operation
4
Operation
12
3
4
56
e3861464a
Pull the emergency off switch (3) if neces-
sary.
Switch on the truck.
Raise the fork arms slightly and tilt the lift
mast backwards.
NOTE
If the red LED in the switch (1) lights up, the
manual parking brake is actuated. Driving is
possible only when the manual parking brake
is released.
If necessary, release the manual parking
brake using the switch (1).
Forward travel
Move the direction selection lever (4)
forwards.
7
8
Display_e0037a
The indicator light (7) lights up.
Press the accelerator pedal (5) carefully.
The automatic brake is released and the
driving speed of the truck increases as the
actuation distance of the pedal increases.
NOTE
Pressing down the accelerator pedal hard is
to no advantage as the maximum acceleration
rate is controlled automatically.
Reverse travel
Move direction select
ion lever (4) back-
wards.
The indicator light (8) lights up.
Press the accelerator pedal (5) gently.
The automatic brake is released and the
driving speed of the truck increases as the
actuation distance of the pedal increases.
Changing the drive direction
Operate direction
selection lever (4) for the
opposite drive dir
ection.
Operating Instructions – 3888011701 EN – 12/2017 115
