Linde E35 - Hydraulic Connection

Safety
2
Fit attachments
Class
As per
ISO 2328
Load
capacity
Truck
kg
Load
centre
of gravity
mm
Design
a
mm
b
mm
c2
mm
i2
mm
h3
mm
A76
1 0 - 999
400 and
600
B114
331 16 13 305
A76
2
1000 -
2500
500 and
600
B152
407 16 13 381
A76
3
2501 -
4999
500 and
600
B203
508 21.5 16 476
A127
4
5000 -
8000
600
B254
635 25.5 19 597
A127
5
8001 -
10999
600
B257
728 34 25 678
Integrated attachments are made to match the
installed lift mast. When fitting attachments
retroactively, the correct attachment and
all necessary parts from the industrial truck
manufacturer—especially lift mast rollers and
chain holders—must be available.
Contact your Service-partner.
Hydraulic connection
WARNING
Hydraulic system is under pressure. Risk of injury.
Wear protective equipment.
CAUTION
Damage t
o the hydraulic system through contami-
nation
.
When
connecting hydraulic lines, ensure they are
cle
an.
Bef
ore connecting hydraulic lines or hydraulic
cou
plings, the hydraulic system must be
depre
ssurised.
Without depressurisation:
 Place a collection container underneath.
 Care
fully release connection of the hy-
drau
lic lines.
Operating Instructions – 3888011701 EN – 12/2017 19
