Operation
4
Loading / transporting
Lashing
4
3
2
1
e3871642
≥ 1m≥ 1m
Requirements for lashing:
• The transport vehicle must be equipped
with lashing points with a load capacity of at
least 2000 daN
• 50-mm polyester lashing straps with a load
capacity of at least 2500 daN must be used
to secure the load
CAUTION
Damage to c
omponents
Components
(e.g. lights, hose lines) must not be
tensioned u
sing the lashing straps.
Lash the truck securely on the right-hand
and left-hand side as shown in the image.
Use edge and surface protection.
For belt (1) and belt (2), select lashing points
that are at least 1 m in front of or behind the
point where the strap loops around the
truck.
Operating Instructions – 3888011701 EN – 12/2017 203
