Linde E35 - Page 297

Technical data
6
Overview of type sheets
3 Wheels, chassis frame
3.1
Tyres: solid rubber, superela
stic, pneumatic
SE
3.2
Front tyre size
355/45-15
(28x12.5-15)
3.3
Rear tyre size
225/75-10
(23x9-10)
3.5
Number of wheels, front/rear (x = driven)
2x/2
3.6 Front track width
b
10
[mm]
1149
3.7 Rear track width
b
11
[mm]
932
4 Basic dimensions
4.1
Lift mast/fork carriage tilt, for-
wards/backwards
α/β (°)
5.0/8.0
4.2
Height with lift mast retracted h
1
[mm]
2404
4.3 Free lift
h
2
[mm]
150
E35/600H
E40/600H
E45/600H
E40/600HL
E45/600HL
E50/500HL
h
3
[mm]
3100
4.4 Lift
E50/600HL
h
3
[mm]
2900
E35/600H
E40/600H
E45/600H
E40/600HL
E45/600HL
E50/500HL
h
4
[mm]
4000
4.5
Height with lift mast extended
E50/
600HL
h
4
[mm]
3900
