Technical data
6
Overview of type sheets
4 Basic dimensions
E35/600H
m
1
[mm]
146
E40/600H
E40/600HL
m
1
[mm]
145
E45/600H
E45/600HL
m
1
[mm]
144
4.31
Ground clearance with load
under lift mast
E50/500HL
E50/600HL
m
1
[mm]
143
4.32 Ground clearance at middle of wheelbase
m
2
[mm]
160
E35/600H
A
st
[mm]
3954
E40/600H
A
st
[mm]
3964
E45/600H
A
st
[mm]
3984
4.33
Aisle width for pallet 1000 x 1200
crosswise
3
E40/600HL
E45/600HL
E50/500HL
E50/600HL
A
st
[mm]
4109
E35/600H
A
st
[mm]
4154
E40/600H
A
st
[mm]
4164
E45/600H
A
st
[mm]
4184
4.34
Aisle width for pallet 800 x 1200
lengthwise
4
E40/600HL
E45/600HL
E50/500HL
E50/600HL
A
st
[mm]
4309
E35/600H
E40/600H
W
a
[mm]
2216
E45/600H
W
a
[mm]
2236
4.35
Turning
radius
E40/600HL
E45/600HL
E50/500HL
E50/600HL
W
a
[mm]
2361
4.36
S
mallest pivot point distance b
13
[mm]
580
3
Including a = 200-mm safety distance
4
Including a = 200-mm safety distance
Operating Instructions – 3888011701 EN – 12/2017 289
