Overview
3
Display unit
1 Display unit
2 Indicator light for direction indicator sys-
tem/hazard warning system (green)
3 Motor temperature at upper limit (red)
4 Neutral warning light (red)
5 Error in electrical controllers or integrated
battery charger (red)
6 Forwards drive direction (single-pedal
operation) (green)
7 Reserve (red)
8 Warning light for assistance system (yel-
low/red)
9 Speed reduction activated (green)
10 Reserve (yellow)
11 Reserve (green)
12 Reverse drive direction (single-pedal opera-
tion) (green)
13 Observe the operating instructions (yellow)
14 Light sensor
Display
15 "Time/date" display
16 "Remaining travel time" display
17 "Function display"
18 "Drive mode" symbol
19 Symbol for "Parking brake applied"
20 Symbol for "Seat belt not fastened" (special
equipment)
21 Symbol for "Lift height restriction active"
(special equipment)
Control buttons
22 "Confirm" button
23 "Down" button
24 "Up" button
25 "Back" button
Display
26 Symbol for "Mast positioning active" (special
equipment)
27 Symbol for "Service interval exceeded"
28 "Malfunctions" menu
29 "Settings" menu
30 "Favourites display" menu
31 "Status display" menu
32 Battery discharge indicator (green/red)
33 Neutral warning light (yellow)
34 Monitoring of rear cover/charger cover
(yellow)
35 Prewarning: motor temperature increasing
(yellow)
36 Battery charging via battery charger finished
(green)
37 Battery charger in charging mode (yellow)
(special equipment)
38 Electronic joystick unlocked (green) or lift
height restriction (green when function-
ing/red for warning) (special equipment)
The display unit (1) is located within the driver's field of vision and is the central information point
for all truck functions. A self-test of the display unit takes place after the key switch has been
switched on. During the self-test, all indicator lights and the displays are activated.
The display unit includes a buzzer to reiterate the visual warning messages.
Press the
button to confirm pop-up messages.
NOTE
If a faulty display unit is replaced, the operating
hours that have been incurred up to that point
must be recorded. Add the information to an
embossed strip affixed near the display unit.
It is also possible to update new display units
during the first 10 operating hours.
Operating Instructions – 3888011701 EN – 12/2017 41
