4
Operation
Driver's compartment
6
3
2
4
1
5
e3871486a
Pull the multifunction lever (6) on the
steering wheel upwards (3) from the centre
position.
As long as the lever is actuate
d, the front
windscreen wiper remains in i
ntermittent
mode and the roof panel wiper r
emains in
continuous mode.
Press the multifunction lever (6) on the
steering wheel downwards (4) from the
centre position.
The front windscreen wiper is in intermittent
mode and the roof panel wiper is in continuous
mode.
6
3
2
4
1
5
e3871486a
Switching on the wiper/washer system
Push in the multifunction lever (6) as far as
it will go in direction (5).
The wiper/washer system is activated for the
windscreen and rear window as long as the
lever is pressed.
Switch on the toggle switch (8).
The wiper/washer system is activated for the
windscreen, rear window and roof panel as
long as the lever is pressed.
84 Operating Instructions – 3888011701 EN – 12/2017
