4
Operation
Driver's compartment
in use, but also the actuation sequence of the
seat switch and belt buckle.
Sit on the driver's seat.
The seat switch is actuated.
Pull the seat belt (2) smoothly out of the
retractor to the left.
Position the belt over the l
ap, not over the
stomach.
Snap the buckle guide (1) into place in the
buckle (4).
10:30
03.03.2015
4
20
h
min
EFF
6
Display_e0060b
Buckle monitori
ng is activated. The "Safety
belt not fastene
d" symbol (6) goes out.
Check the seat belt tension.
The belt must sit close to the body.
NOTE
If the seat switch is not actuated and the seat
belt is not fastened, the truck will not move
at all or will only move at creep speed. The
symbol (6) lights up.
Releasing the seat belt
Push the red button (5) on the buckle (4).
Manually feed the buckle guide (1) back into
the retractor (3).
NOTE
The automatic blocking mechanism may be
triggered if the web belt runs in too quickly and
the buckle guide strikes the housing. The web
belt cannot be pulled out with the usual force.
88 Operating Instructions – 3888011701 EN – 12/2017
