WP-C R1 Max 30kg d= 0.0005kg
000002
+
kg
xBPI scale setup @admin
Calibration check
NET
input
Done
20.0000 kg
20.00000 kg
Accept Reset error Cancel
4.7.5.3.5 Adjust with default weight
In this menu item, the xBPI scale weighing electronics are calibrated with a default
weight.
Requirements:
- The xBPI protocol has been selected, see Chapter 4.7.5.1.
- The [xBPI scale] weighing point has been selected, see Chapter 4.7.5.
- The scale has been set up, see Chapter 4.7.5.5.
- [Manual] has been set in the menu [Operating] - [System setup] - [Weighing points] -
[Weighing point x] - [Setup] - [Conguration] - [Weighing parameters] - [Conrm
calibration] , see Chapter 4.7.5.5.1.1.
- The communication between the device and xBPI scale is active.
- the xBPI scale parameters have been read, see Chapter 4.7.5.3.
Accessible via MENU - [Operating] - [System setup] - [Weighing points] - [Weighing
point x] - [xBPI scale] - [Calib] - [Adjust with default weight] .
WP-C R1 Max 30kg d= 0.0005kg
00000
kg
xBPI scale setup @admin
Adjust with default weight
Adjust with internal weight
Linearisation
Default linearisation
User linearisation
4. Remove the weight.
5. Press the EXIT key to return to the xBPI setup menu.
1. Select and conrm [Adjust with default weight].
The calibration process is performed without a weight and the calibration check
indicates the status.
