1.1 Connections and Functions Supported by GOT
1 - 5
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION
TO CPU
4
COMPUTER LINK
CONNECTION
5
MELSECNET/10
CONNECTION (PLC TO
PLC NETWORK)
6
CC-Link CONNECTION
(INTELLIGENT DEVICE
STATION)
7
CC-Link CONNECTION
(Via G4)
8
ETHERNET
CONNECTION
2 Connection with another manufacture's PLC
Since the GOT can monitor a PLC manufactured by a vendor other than Mitsubishi, the flexible system
configuration is available.
• OMRON PLC ( Chapter 9 CONNECTION TO OMRON PLC)
• KEYENCE PLC( Chapter 10 CONNECTON TO KEYENCE PLC )
• SHARP PLC ( Chapter 11 CONNECTION TO SHARP PLC)
• TOSHIBA PLC ( Chapter 12 CONNECTION TO TOSHIBA PLC)
• HITACHI PLC ( Chapter 13 CONNECTION TO HITACHI PLC)
• MATSUSHITA PLC ( Chapter 14 CONNECTION TO MATSUSHITA PLC)
• YASKAWA PLC ( Chapter 15 CONNECTION TO YASKAWA PLC)
• YOKOGAWA PLC ( Chapter 16 CONNECTION TO YOKOGAWA PLC)
• Allen-Bradley PLC ( Chapter 17 CONNECTION TO ALLEN-BRADLEY PLC)
• SIEMENS PLC ( Chapter 18 CONNECTION TO SIEMENS PLC)
3 Connection with devices other than PLCs
The GOT can monitor devices other than PLCs.
4 Various useful functions
The GOT offers various functions convenient for connection with the PLC CPU.
Devices Application Reference
Microcomputer
This type of connection allows data reading/writing to a
virtual device on GOT from a PC, microcomputer board,
PLC, etc. (hereinafter, referred to as host).
Interrupt output is also available from a GOT to a host.
Chapter 19 MICROCOMPUTER
CONNECTION
Temperature controller
Various kinds of monitoring and parameter change are
available to temperature controller.
Chapter 20 CONNECTION TO
OMRON TEMPERATURE CONTROLLER
Chapter 21 CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
Chapter 22 CONNECTION TO RKC
TEMPERATURE CONTROLLER
Inverter
Various kinds of monitoring and parameter change are
available to inverter.
Chapter 23 INVERTER
CONNECTION
Servo amplifier
Various kinds of monitoring and parameter change are
available to servo amplifiers.
Chapter 24 SERVO AMPLIFIER
CONNECTION
Bar code reader
Data read by the bar code reader can be written to the
PLC CPU.
Chapter 25 BAR CODE READER
CONNECTION
Printer
The printing data in GOT can be printable to a PictBrige
Compatible printer.
Chapter 26 PRINTER CONNECTION
CNC
Various kinds of monitoring and parameter change are
available to CNC.
Chapter 27 CNC CONNECTION
Devices Application Reference
Multi-channel function
Installing two or more communication units and
communication drivers in GOT, one GOT can monitor
maximum four FA controllers (PLC CPU, temperature
controller, inverter etc.).
Chapter 28 MULTI-CHANNEL
FUNCTION
FA transparent function
With the GOT connected to a Mitsubishi PLC, a personal
computer can be connected to the GOT and the
sequence programs in the PLC can be read from or
written to the computer via the GOT.
Chapter 29 FA TRANSPARENT
FUNCTION
To Next Page
