102 MI-42-0001 Rev. 19
SCANNING: Typical Scan Sequence: New Scan
Figure 73
Figure 74
Step
Select the A-P or Lateral view.
When either are selected for Helical scans,
Modulated Scan Available
(see Figure 73 a) is
checked (see Figure 74 s).
NOTE: Modulated scanning is only available in the Helical Scan workflow after running either an
A-P or Lateral scout scan.
