Appliances --- Section 4
The Executive 2005
169
• ON/OFF Button - Turns the refrigerator on or off.
- Push the ON/OFF button to start the refrigerator in Auto mode.
- Push and hold the ON/OFF button for two seconds to shut it off.
• LED Display - This screen is used for mode, temperature and fault code display.
• MODE Button - Controls the operation mode of the refrigerator.
- Push and hold the MODE button to select between Automatic AU, AC or LP operation.
• SET TEMP Button - Adjusts the temperature.
- To adjust push and hold the SET TEMP button.
- Number "9" is the coldest setting.
Manual Mode:
When one of the two manual modes is selected:
1. AC = The refrigerator is operating on AC electric.
2. LP = The refrigerator is operating on LP-Gas.
Automatic Mode (AV):
This feature selects AC over LP-Gas operation. If AC discontinues the alarm sounds and the refrig-
erator switches to LP-Gas operation. If the refrigerator fails to light, the alarm sounds and a code dis-
plays.
• Press and hold the MODE button until AU displays. Release the button.
• Press and hold the TEMP SET button until the desired temperature displays. Release but-
ton.
• In AUTO mode, AU/AC or AU/LP will alternate 3 times when a mode has changed.
If the LP-Gas does not ignite within 30 seconds, the control changes to a different energy
source or the gas safety valve closes and “NO” “FL” displays. Turn the refrigerator off then back on.
If the gas does not ignite after several attempts consult a dealer or authorized Norcold service center.
030864
The Refrigerator Control Panel requires 12 Volt DC to operate.
Control Panel
