Monaco Executive 2005 - Four-Channel Remote (OPT); Window Awning - Girard (OPT); Door Awning - Girard

Equipment --- Section 5
The Executive 2005
229
Four-Channel Remote (Optional)
The four-channel remote can control up to four awnings and is used
on the patio awning and the automatic window awnings. Press the
round channel selector button at the bottom of the remote to toggle
through the different channels. One of the four LED's above the chan-
nel selector that corresponds to the appropriate awning will illuminate.
Window Awning - Girard (Optional)
The Girard window awning uses 120 Volt AC to operate.
To Extend or Retract the Awning:
• Hook to shore power, start the generator or turn on the inverter.
• Use the 4 channel remote to extend or retract the awning. Awning will extend or
retract full distance and automatically stop. Awning may be set to any position by
pressing the stop button.
Door Awning - Girard
The Girard door awning uses 120 Volt AC to operate.
To Extend or Retract the Awning:
• Hook to shore power, start the generator or turn on the inverter.
• Use the control above the passenger chair to extend or retract the
awning. Awning will extend or retract full dis-
tance and automatically stop.
• Awning may be set to any position by pressing
the center button on the control. The awning
is strongest in the fully extended position.
Changing the Front Door Awning Switch
Battery:
• Remove switch plate.
• Remove switch unit from cabinet.
• Remove back cover.
• Lift tabs to release battery.
• Replace with new battery and re-install.
060240b
060240b
Retract
Stop
Extend
Bed
Window
Wardrobe
Window
Roadside
Window
Channel
Selector
Patio
Four Channel
Remote
Four Channel
Remote
060240d
060240e
Face Plate
Remove back to replace battery.
3V Lithium
battery CR2430
Lift tabs
and tilt to
release
battery
