Section 10 --- Chassis Information
The Executive 2005
502
Rear Start Switches
The rear start switches are for safety and convenience. The front/rear switch
has three positions:
1. FRONT - Motorhome will only start with the ignition key.
2. REAR - Motorhome can only be started with the rear start switch.
NOTE:
The Ignition switch must also be in the “on” position.
3. OFF - Starter will not engage with either ignition key or rear start switch.
It will also turn the engine off if it is already running.
The Start switch engages the starter when the front/rear switch is set to Rear and the ignition
switch is on.
HYDRAULIC SYSTEM
The motorhome uses an engine driven hydraulic pump to operate both the power steering and
engine hydraulic cooling fan systems, sharing one common reservoir. The hydraulic fluid used is an
automatic transmission fluid (Dexron III
®
) which has a wide ambient temperature operating range.
CAUTION:
If ambient temperatures approach 0º F, Pennzoil Arctic Blue hydraulic fluid, or
equivalent hydraulic fluid, should be used. Using incorrect hydraulic system fluid
weights in cold temperatures will raise the hydraulic system operating pressure
and may damage the hydraulic cooler.
090373h
100188
Typical System: May vary with engine type.
