Section 5 --- Equipment
The Executive 2005
248
Power Down VCM:
Select POWER DOWN VCM to enter Low Power mode, and turn
off sensor modules. Low Power mode is cancelled when any joystick
module is touched.
Turning off the ignition will cause the Aladdin™ to power down. A
ten-second countdown is performed prior to power down. Joystick
action will abort this countdown and the Aladdin™ will remain on. The
Aladdin™ can be manually powered down when desired by selecting
the POWER DOWN VCM. If the joystick is not touched before the countdown, and the Aladdin™
has powered down, the joystick touch will cause the Aladdin™ to power back up.
System Options
The SYSTEM OPTIONS screen provides the operator with a
submenu for Aladdin™ functions that are less frequently used, and
includes screen appearance adjust. Only service personnel should
use SYSTEM SETUP to program a new system. To assist the
service technician in troubleshooting system problems, the SEN-
SOR MODE may be used.
Screen and text colors are selected by accessing the menu item
using joystick up and down. Move the joystick right to sequence
through the seven available colors. Colors selected will be imme-
diately displayed. Colors selected will be stored and remain in
effect until changed, even if the Aladdin™ is powered down.
The usual SENSOR MODE is NORMAL. Additional options are RAW and VERSION. RAW
mode causes the sensor modules to display raw, unmodified/calibrated data from their sensors, and
might be used by technicians troubleshooting the system. VERSION mode causes the sensor modules
to display internal software version numbers.
Compass calibration is used to match the compass module to the motorhome, and may be per-
formed as needed.
Compass Calibration
The COMPASS CALIBRATION system allows the operator to match the motorhome to the com-
pass module. Calibration is accomplished by selecting START CALIBRATION, then driving the
motorhome in a full 360° circle. At the end of driving this loop, select STOP CALIBRATION. At this
time the Aladdin™ will request calibration status from the TCM (Temperature Compass Module). A
successful calibration will cause a "Calibration Successful" message to be displayed. A calibration
that fails will display "Calibration Fail" and a failure code.
NOTE:
Other Aladdin™ functions and screens are discussed in respective sections of this
manual.
SYSTEM OPTIONS
ALADDIN MODEL 440 2.04
JOYSTICK F/W VERSION 2.01
SCREEN COLOR: 01
TEXT COLOR: 16
SENSOR MODE: NORMAL
SYSTEM SETUP
COMPASS CALIBRATION
020218d
