Section 5 --- Equipment
The Executive 2005
244
CELL PHONE ANTENNA
The motorhome is equipped with a cell phone antenna. The
antenna lead is located behind the dash instrument cluster. To
access the lead, remove the inspection panel located on top of
the dash pad. The antenna lead run is installed in the section
between the drivers side window and the windshield. The coiled
antenna lead should be located toward the front firewall,
directly behind the instrument cluster.
KENWOOD RECEIVER-MONITOR
This system uses an in-dash, 7" color video monitor and a
Sirius® Satellite Radio Ready AM/FM receiver. The 7" video
monitor will display the navigation and radio system informa-
tion.
NOTE:
The radio systems operate with the radio remote con-
trol or from the radio touch screen labels.
Power Requirements:
• Main battery disconnect switch (located in the battery com-
partment) must be on.
• Turn ON the interior house power using the battery cut-off
switch.
• The ignition key must be in either the ON position or the ACC position.
To View:
• Press the OPEN button.
• The steering wheel may interfere with the monitor while opening. If this occurs, move the
steering column (ensure this can be performed safely) before operating the set. The monitor
will automatically retract if it cannot open due to an obstacle.
• The monitor position is adjustable. Refer to the angle control screen of the Kenwood
Monitor-Receiver instruction manual.
Closing the Monitor:
• Press the OPEN button again to close the monitor
Power Controls:
• Press the SRC button for at least one second to Power ON the monitor.
• Press the SRC button again to Power OFF the monitor.
INFORMA
TION:
For more detailed instructions on the monitor or receiver, refer to the Kenwood
Monitor-Receiver instruction manual.
031050
030866
Cell Phone Antenna
