Section 5 --- Equipment
The Executive 2005
236
DINETTE BED CONVERSION (Optional)
To Convert Booth Dinette into a Bed:
• Lift seat cushions to an angled vertical position.
• With a firm grip, lift front edge of the table approxi-
mately six inches and push table leg lock to side.
• Swing the table leg up and lock into a horizontal
position.
• Continue lifting table until table stays are clear of
retainers. Pull outward and lower table down.
• Use both seat cushions and one back cushion for a
mattress. Leave one back cushion in a vertical position.
WARNING:
Do not occupy the booth dinette, if not equipped with safety belts, or the dining chairs
while the motorhome is in motion. To avoid personal injury to occupants in case of a
crash or sudden stop, chairs must be stored in an enclosed area or secured with tie
down straps while the motorhome is in motion.
AIR MATTRESS BED
The air mattress pump is located in the bed storage compartment and is plugged into a 120 Volt AC
outlet. Two remotes are used to adjust the firmness setting of each side of the mattress. Only one
side of the mattress may be adjusted at a time. When one remote is being used, the other remote is
inoperative.
To Operate Mattress:
There are two modes that can be used to adjust the mattress firmness: Manual (1) mode and the
Pressure Sensitive (2) mode.
The air mattress reads body weight to make proper adjustments and requires someone to be on the
mattress when adjusting firmness settings in both the Manual and Pressure Sensitive modes.
To Select Modes:
Hold the MODE button down until the remote beeps, then release. The display will read 1. Use the
+ and - buttons to alternate between Manual and Pressure Sensitive modes. To enter the mode that is
selected (1 or 2) hold down the MODE button again until the remote beeps. To return to mode select,
at any time, press and hold the MODE button down until the remote beeps.
020163
