Water Systems --- Section 6
The Executive 2005
271
WATER - HOSE REEL
The convenience of the water hose reel eliminates the need
to store a potable water hose in the bay. Use the hose reel for
city water hook-up or to fill the fresh water tank. The reel is
equipped with a 35 foot hose and a 12 Volt DC motor that will
rewind the hose after use. The water reel is located in the road-
side bay.
City Hook-Up
• Remove hose plug and install a water pressure regulator to the water
hose.
• Connect the water hose to a City Water hook-up.
• Turn the city water/tank fill valve to the City Water - Closed position.
• Turn on the water supply.
• The water pump can either be off or on. It will not affect the water
pump to leave it on.
CAUTION:
Some outside water sources develop high water pressure, par-
ticularly in mountainous regions. High water pressure is any-
thing over 55 psi (pounds per square inch). An additional pres-
sure regulator can be connected to the city water faucet to reg-
ulate the pressure to the potable water hose. Excessive water
pressure may cause leaks in water lines and on a hot day, cause
the water hose to swell and burst.
040480k
Retract
Switch
3 amp Reset
Breaker
040480E
Water Pressure Regulator
Attached to Hose Reel
040527
Located in roadside bay in front of
plumbing service center.
Tank Fill/City Hook-Up
valve located in hose reel
bay.
