Section 6 --- Water Systems
The Executive 2005
290
TOILET
The toilet uses water from either the fresh water tank or a city water supply. The water pump must
be turned on or connect the motorhome to city water. The toilet uses 12 Volt DC to flush. The toilet
flushes directly into the sewage holding tank (black water).
To Add Water to the Toilet:
Lift the flush lever until the desired water level is obtained. Generally, more water is required when
flushing solids.
To Flush the Toilet:
Momentarily push the lever down. Holding the lever down will not increase flush time or water
flow. The flush cycle is a timed event controlled by a microprocessor. Water pressure and flow rates
vary with location. It may be necessary to adjust the water level.
NOTE:
The toilet requires 12 Volt DC to operate. Low voltage will cause toilet malfunction or
failure.
040449C
Lift the lid to access
the control switches.
Flush
Lever
Toilet with lid removed
