WALL THERMOSTAT
Comfort Controls to operate the HVAC (Heating, Ventilation and Air
Conditioning systems) are located in the living room and in the bedroom.
The living room Comfort Control operates the front roof air conditioner
functions, and the Aqua-Hot living room heat exchangers. The bedroom
Comfort Control operates the rear roof air conditioner, mid-roof air conditioner
and the Aqua-hot bathroom and bedroom heat exchangers. Both Comfort
Controls use a liquid crystal display to show the current mode status.
The HVAC system provides five different functions: Off, Fan, Cool,
Heat Pump and Furnace that are selected by pressing the Mode button.
Fan controls blower speed of the roof air conditioner. Three speeds are
available - low, medium and high. Selecting fan speed Auto adjusts the fan
speed automatically, based on temperature set point and actual temperature
in a selected zone. When Auto Fan is selected in Cool or Heat mode, blow-
er speed is limited to low or high.
The motorhome is divided into three operating zones: front, middle and
rear. The selected Zone will flash. Control individual zone temperatures
using the UP or DOWN buttons.
Living Room = Zone One
Middle = Zone Two
Bedroom = Zone Three
NOTE:
The bedroom is designated Zone One at the Bedroom Comfort Control.
NOTE:
The Comfort Control must be ON to operate any HVAC function. Do not select con-
flicting modes of operation. One zone cannot be on Cool while another zone is set to
Furnace.
NOTE:
The motorhome will not heat or cool faster by selecting a very high or very low tempera-
ture setting.
NOTE:
Only one of the following can be used at a time: Bedroom A/C, Washer-Dryer, or
Cooktop. This is due to the automatic appliance selector limiting the use of appliances
according to priority, to prevent electrical overload.
050200b
030950
Remote Temperature Sensor
