Section 5 --- Equipment
The Executive 2005
242
LADDER - REAR
The rear-folding ladder allows access to the roof. Care should be used
when climbing the ladder. Access to the roof should be limited to cleaning and
sealing purposes only. Fold ladder to the up position to open rear engine access
doors.
To Raise Ladder:
• Remove the hairpin cotter clip from the clevis pin.
• Fold ladder upwards. Hinges will gravity lock into
the upright position.
To Lower Ladder:
• Push up on lower section of ladder to unlock
hinge.
• Lower ladder. Engage ladder legs with bottom
locks.
• Install clevis pin and hair pin clip.
NOTE:
Maximum weight capacity for the ladder is
300 lbs.
070189
070189b
