Section 10 --- Chassis Information
The Executive 2005
454
Lubrication Maintenance
The tag axle slack adjuster and “S” cam shaft need to be lubed periodically to ensure proper brake
operation. Lubricate every 10,000 miles or 3 months.
TAG AXLE
The switch for the tag axle is located on the roadside switch panel. Two
lights are located on the switch: The tag axle icon will illuminate with the park
lights. The lower bar light will illuminate when the tag axle switch is on and
the transmission is in neutral, reverse or first gear. When the transmission is in
2nd - 6th gear and the tag axle is covered, the light will be off. Raise the tag
axle when performing severe or tight maneuvering under 5 mph to prevent
scuffing the tag axle tires. A beeping alarm sounds when the switch is on.
The tag axle raises in the following modes:
• Interior house power must be ON.
• When the switch is on and the transmission is in Neutral,
Reverse or First Gear.
• With the tag axle in the up position there is not a specific
height requirement other than the tire should be off the
ground. If extra clearance is desired, moving the lift chain
up one link on each side can increase ground clearance
with the tag axle in the raised position.
090433
TAG
AXLE
060066
080375
Tag Axle
Lighted Switch
Light is activated with
Park Lights
