Section 4 --- Appliances
The Executive 2005
196
ELECTRIC BASEBOARD HEATER (Optional)
The baseboard heater operates from 120 Volts AC supplied by shore power or
the generator. An adjustable thermostat and remote switch controls the operation of the
heater.
To Operate the Heater:
• Hook to shore power or start the generator.
• Adjust thermostat to desired setting.
• Turn on the Heater switch.
NOTE:
The heater is rated at 1000 watts or 8.8 Amps. Use care when
hooked to anything less than 50 Amp service.
TIP:
If heater operation discontinues or fails to operate, check the
power supply. If the heater still does not operate, the Temperature
Overload Switch may be tripped.
To Reset the Overload Switch:
• Turn off power supply.
• Remove grille to access the Overload switch.
• Using a pencil or small screwdriver, press the red Reset button down.
030939
030940
080433
Base
Board
Heater
