Electrical Systems - House --- Section 8
The Executive 2005
345
Inv/Chg Current:
Measures the AC current usage when the inverter is charging.
Inverter Output VAC:
Monitors the AC output voltage while the unit is inverting.
AC Input Amps:
The inverter uses a double pole pass through relay, measuring current consumption through
the Hot 1 terminal.
Battery Temperature:
Monitors counts of the battery temperature sensor (BTS). Counts are measured impulses
which the inverter uses to calculate the battery case temperature. The charging voltage is adjust-
ed to optimum values.
Xformer Temp:
Monitors the transformer temperature which is measured in counts. Higher count readings are
registering lower temperatures.
FET Temp:
Monitors the Field Effect Transistor temperature which is measured in counts.
Est Batt Cap:
Estimates the battery bank capacity in amp hours (Ahrs). Charging and discharging on a
cyclic basis will give an approximate indication of the battery capacity in amp hours. Observe
the reading and multiply by eight to obtain an approximate reserve capacity. This figure is only
approximate and will change with cyclic use.
Programming the Inverter
The factory settings of the inverter will work in most situations. Before changing program values
consult the Inverter Manual for complete details.
To enter programming mode:
• Press and hold the up and down arrows for five seconds. The RC7 GS remote will beep.
• Release the buttons. The programming mode has been entered when the Search Sense is
displayed.
• Use the up and down arrows to scroll though available field settings.
• Use the right-pointing arrow to scroll through available settings for selected field.
