Battery Temp/Comp Volts DC - Displays the bulk voltage setting in the menu item Set
Bulk Volts DC under the menu heading Battery Charging Number 10. Actual charge
voltage will differ depending on ambient temperature. This is due to battery temperature
compensation.
Inverter Volts AC - Displays the inverter's AC output voltage.
Grid (AC1) Volts AC - Not used.
Generator (AC2) Volts AC - Displays the incoming line voltage from either shore power
or generator to the inverter.
Read Frequency Hertz - Displays the number of cycles per second of incoming power
to the inverter.
Automatic Generator Start Programming
Procedure to program the automatic generator start function:
There are several variables to the program. Some settings may work fine in one location, but not in
another. The order of instructions will follow the sequence of the headings. Read all instructions thor-
oughly. This is not a substitute for the inverter manual.
Setting the Clock (24 hour):
1. Using the Menu Headings buttons scroll to menu number “6 Time of
Day.”
2. Press the DOWN button on the Menu Items button, Set Clock Hour will
display. Use the Set Point buttons to set the hour. Time changes in ten
minute increments. The clock is a 24 hour clock. For example: 9:00 a.m.
would be 09:00, 3 p.m. would be 15:00 and 7 p.m. would be 19:00.
3. Press the DOWN button on the Menu Items button, “Set Clock Minute”
will display. Use the Set Point buttons to set the minute.
4. Press the DOWN button on the Menu Items button, “Set Clock Second”
will display. Use the Set Point buttons to set the second.
Setting Generator Timer:
5. Press the Menu Headings DOWN button, Menu Heading number “7 Generator Timer”
will display.
6. Press the DOWN button on the Menu Items button, “Start Quiet Time h:m” will display.
Start Quiet Time is the time you want the generator to stop running or not start at or after
quiet time begins. Using the Set Point buttons to set the hour and minute (24 hour clock)
the generator will start quiet time.
