Section 8 --- Electrical Systems - House
The Executive 2005
344
Main Menu Display
The Main Menu displays operating status of the inverter. Use the Up or Down arrows to scroll
through the Main Menu.
Waiting for AC:
System inactive waiting for AC power to be supplied.
Inverting:
Unit is inverting.
Charging Cycle Status:
Bulk, Absorb or Float mode.
Battery State of Charge:
Based on the Fuel Gauge Cutout setting. May be displayed in percentages or as a fuel gauge.
Time Left To Run:
Evaluates the battery reserve capacity at current operating load based on the Fuel Gauge Cutout and
Battery Bank Capacity settings.
Time Left To Charge:
Estimated time left to charge batteries to full state of charge based on Fuel Gauge Cutout and Battery
Bank Capacity settings with current battery voltage.
Generator Start/Stop:
Use inverter ON/OFF button to remotely start the generator, or to override automatic generator start fea-
ture for manual operation. This feature is available to use without altering automatic generator start
programming.
Meters Menu
The Meters Menu displays specific numeric accounts of the inverter.
To Access the Meters Menu:
• Press and hold the UP arrow for five seconds. The RC7 GS remote will beep. Release the
button. Avg Shunt Amps should be displayed. Use the Up or Down arrows to scroll the
field. This field area includes:
Avg Shunt Amps:
Measures the DC current either charging or discharging. Most of the house DC current usage is
monitored by the inverter.
Battery Voltage:
Monitors the house battery voltage.
