Electrical Systems - House --- Section 8
The Executive 2005
351
Navigating the Menu:
• Pressing a Menu Headings button enters Menu Heading numbers 1 to 8, referred to as the
User Menu.
• Pressing the red and green buttons simultaneously will access Menu Heading numbers 9 to
20, this is the Setup Menu.
• Use the Menu Headings UP or DOWN arrows to scroll the various main headings. A num-
ber in the lower right hand corner of the screen indicates the number of the heading.
• Use the Menu Item UP or DOWN arrows to scroll the various sub-heading of a Menu
Heading.
• Use the Set Points UP or DOWN arrows to change the values of a subheading.
NOTE:
A complete description of the Menu Headings and Menu Items are listed in the invert-
er manual. Refer to the list when accessing the menu or changing program values.
Red Button:
Press the red button to scroll the cursor. An underscore of the first letter indicates the selected
mode. Press the red button to turn ON the inverter, battery charger or quickly exit programming
mode and return to Menu Heading number 1, Inverter Mode.
OFF - Turns the inverter and charger off. The charger will not activate in this mode when AC
power is available.
SRCH (Search) - Turns the inverter on when a specified load, rated in watts, is applied to the
inverter. Generally, there are enough loads to turn the inverter on in this setting.
ON - Turns the inverter on regardless of load. When AC is available the charger turns on and the
inverter goes into Stand-by mode.
CHG - Turns the charger on when AC is available. If AC power discontinues, the charger will stop.
NOTE:
When hooked to shore power, or operating the generator, use the red button to enter a
charge mode by selecting either On or Chg in the main menu. Failure to enter a
Charge mode will result in dead house batteries.
