Electrical Systems - Chassis --- Section 9
The Executive 2005
409
MAX A/C - Recirculated air is drawn from the passenger area and discharged
through the dash louvers.
A/C - Fresh Air is drawn from outside into the system and discharged through
the dash louvers.
VENT - Fresh air is drawn in and discharged throughout the dash.
OFF - The blower motor does not operate. The fresh air inlet door will close,
minimizing outside air infiltration into the motorhome.
BI-LEVEL - Fresh air is drawn in and discharged through the dash and the
floor.
FLOOR - Fresh air is drawn in and discharged through the floor louvers.
MIX - Fresh air is drawn in and discharged through the floor and defrost lou-
vers. The A/C system operates to dehumidify the discharged air.
DEFROST - Fresh air is drawn in and discharged through the defrost louvers.
The A/C system operates to dehumidify the discharged air.
TEMPERATURE CONTROL SWITCH:
Controls an electric water valve regulating the amount of engine coolant passing through the heat-
ing and cooling coils in the system. Rotating to the red area provides warmer air; rotating to the blue
area provides cooler air.
NOTE:
The temperature controls which must be set to the blue zone for cool air.
NOTE:
Activate the A/C system mostly to keep internal components of the compressor lubri-
cated.
BLOWER CONTROL SWITCH:
Controls the speed of the blower motor, which is one of the best and most effective ways of control-
ling the temperature. The switch provides four speeds in all modes except OFF.
MAX
A/C
A/C
OFF
