NICE1000
new
User Manual Troubleshooting
- 179 -
Fault
Code
Name Possible Causes Solution Level
Err05
Overvoltage
during
acceleration
The input voltage is too
high.
The regeneration power
of the motor is too high.
The braking resistance is
too large, or the braking
unit fails.
The acceleration rate is
too short.
Adjust the input voltage.
Observe whether the bus
voltage is normal and whether
it rises too quickly during
running.
Check for the balance
coefcient.
Select a proper braking
resistor and check whether the
resistance is too large based
on the recommended braking
resistance table in chapter 3.
Check:
־ Whether the cable connecting
the braking resistor is
damaged
־ Whether the cooper wire
touches the ground
־ Whether the connection is
reliable
5A
Err06
Overvoltage
during
deceleration
The input voltage is too
high.
The braking resistance is
too large, or the braking
unit fails.
The deceleration rate is
too short.
5A
Err07
Overvoltage at
constant speed
The input voltage is too
high.
The braking resistance is
too large, or the braking
unit fails.
5A
Err09 Undervoltage
Instantaneous power
failure occurs on the
input power supply.
The input voltage is too
low.
The drive control board
fails.
Eliminate external power
supply faults and check
whether the power fails during
running.
Check whether the wiring of all
power input cables is secure.
Contact the agent or Monarch.
5A
Err10
Controller
overload
The brake circuit is
abnormal.
The load is too heavy.
The encoder feedback
signal is abnormal.
The motor parameters
are incorrect.
A fault occurs on the
motor power cables.
Check the brake circuit and
power input.
Reduce the load.
Check whether the encoder
feedback signal and setting are
correct, and whether the initial
angle of the encoder for the
PMSM is correct.
Check the motor parameter
setting and perform motor
auto-tuning.
Check the power cables of the
motor (refer to the solution of
Err02).
4A
